Alfa Term 20 Boiler Range

Alfa Term 20 Boiler Range

The Alfa boiler range cooker is a high-quality and very efficient multi-fuel cooker. This range provides an excellent 14.2 kw heat output to the radiators and 8.7kw heat output to the room. The Alfa has outstanding cooking and baking capabilities through its large hot plate and high-quality stainless-steel oven. With fast heat-up time, it’s the perfect heating solution for houses with a max of 14 radiators. This range is available in red, white, brown, and anthracite finish.

Dimensions W900mm, D600mm, H850mm

Specification:

• 14.2 kW output to radiators
• 8.7 kW output to room
• Fuel: Multi-fuel (coal, wood, turf)
• 3 flue options are available: top, top/back, side
• Heating Volume 345 – 575 m3
• Heating area 138-230 m2
• Diameter of flue 150mm/6”
• Large hob for cooking 889mmx483mm (W x D)
• Boiler 14L
• Large oven 440mm x 460mm (W x D)
• Simple to use and easy to maintain
• 5-year warranty on boiler

Additional Information:

• Alfa Range has a Built-in hot water boiler for a central heating system.
• Cast iron grate.
• Equipped with a manual damper for controlling the secondary air supply
• The special key for opening the stove in case the handles become too hot.
• Equipped with removable steel hot plates and an oven.
• The oven has a double-layered glass and a built-in thermometer.
• Equipped with a thermometer and manometer to monitor the water temperature in the boiler.
• This Alfa range is equipped with two regulators – one for the stove and an automatic one for the water in the boiler.
• Regulator for a secondary burning and combustion of flue gases, in cases where coal is used.
• Combustion of the fuel can be done through the removable hot plates.
• Two operation modes – summer and winter.
• Fuel storage drawer in the lower part of the cooker.
• Built-in emergency heat evacuator in case of overheating

Warning!

Not to be fired when not connected to radiators/fan convector heaters. Burning fuel in this boiler range without water in the boiler will cause it to crack.

Achieving the desired heat output depends on the selected fuel with the necessary caloricity and humidity; its subsequent kindling and refuelling; the regulation of the primary and the secondary air as well as the draught; the organizing of effective air heat exchange etc.
